Meet all changes with strength

N40 Internet of Things Handheld terminal

2D

NFC

WIFI

Lighter than you can imagine

Nine grid physical key combination, soft glue and hard glue mutual cooperation, ergonomic design, soft and comfortable touch.

4G full network

Support mobile/Unicom/telecom, dual frequency WIFI, Bluetooth transmission greatly reduce the network delay problem.

High performance scan engine

Quickly and accurately capture and identify one - and two-dimensional codes even if they may be scratched, folded or smudged.

This moment, more clear

8 million pixel rear, support auto focus, flash, anti-shake, macro shooting, effectively improve the weak light, so that the picture is clear and stable, users more flexible and convenient use.

NFC module expands more possibilities

With NFC read and write function, read and write distance of 2 to 5 meters to expand more card swipe scenarios.

Strong performance from the core

More powerful and lower power consumption of eight core processor, multi-task easy switching without deadlock, more powerful performance, give you a more smooth and enjoyable experience.

IP66 industrial protection grade

Anti-fall, waterproof, dust-proof, 6 surfaces can withstand the impact of 1.5 meters falling into the marble, easy to deal with a variety of scenes.

High strength and long endurance

4500mAH large capacity battery can be detachable, lasting up to 8-12 hours to meet the needs of the whole day's work

N40 Specifications
Download
Standard configuration
Operating system
Android 10.0
CPU
Cortex-A53 quad-core/octa-core,1.3/2.0GHz
RAM+ROM
2GB+16GB
3GB+32GB
4GB+64GB
Display screen
4 inch,480x800
Mobile Network
4G full network
WIFI
Dual-band 2.4GHz/5GHz supports IEEE 802 a/b/g/n/ac protocol
Bluetooth
Bluetooth 4.0/5.0+BLE
Interface
Type-C 2.0 USB x 1, OTG
Dimensions
162mm x 71.5mm x 17 (thinnest) mm
Keypad
25 soft and hard rubber keys, left key x1, right key x1
Card slot
NANO SIM card x 2
TF Card x 1(optional PSAM)
POGO Pinx1
GNSS
GPS,Galileo,Glonass, Beidou
User Environment
Operating Temp: -20℃ to 55℃
Storage Temp: -40C to 70℃
Camera
Rear camera 8MP
Front camera 2MP (N40A/N40B)
Sealing
IP66,1.5m drop test
Battery
3.8V 4500mAh
Optional configuration
1D Scanner
Mindeo SE966
Honeywell N4313
2D Scanner
Mindeo E483 New World N6601 Honeywell N6603 N5703 N6703 and N6602
NFC
13.56MHz,support ISO14443A/B, 15693 protocol
